TM-288 Thermal stress measuring device

Features

• In compliance with JIS B 7922 Level 2

• Three applications: arm band, tripod, and hanging.

• High-sensitive capacitive humidity sensor and bandgap temperature sensor.

• Measure the WBGT, black-globe temp. (TG), Air temp. (TA), humidity (%RH).

• Low voltage indicator

• °C or °F selectable.

• With the plastic black-globe of the diameter Ø40mm.

• Three-stage WBGT alarm selectable:      mute (buzzer not displayed), cyclic setting.

• Outdoor or indoor (default is OUT) measurement mode selectable.

• Sampling interval: per 20 seconds

• Operating wind speed: 0.3 m/s or above.

• Operation temperature and humidity: 0°C to +50°C,<80%RH (No condensation)

• Storage temperature and humidity: 0°C to +60°C,<70%RH (No condensation)
