CM-200S A portable device for measuring and analyzing colors

The meter is an extremely compact, extremely easy-to-use tristimulus colormeter specially designed for measuring the color difference between two colors.

The meter is designed for measuring the color of no lighting and non-fluorescent sample such as textile, paper, leathers, painting materials, etc. It is the useful tool for the quality control and wide industrial application.
* Color difference displayed (L*, a*, b*), (E*ab, C*ab, H*ab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw).
* Color space displayed (L*, a*, b*), (L*, C*ab, hab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw).
* Statistical function (Maximum, Minimum, Average and Standard Deviation).
* Color difference tolerance set to perform PASS / WARN / FAIL.
* Store 9 color-difference target colors.
* User calibration function ensures higher accuracy.
* Auto memory (99 sets) & Read function.
* Digital backlight display.
* Auto power off function.
* Applies USB, Bluetooth data output.
* Use USB data output to connect with PC.

Display

Triple 4 digit LCD Display

Auto power off

Approx. 3 minutes

Data memory capacity

99 set. (Direct reading from LCD display)

Low battery indication

√

Illuminating/Viewing geometry

45°/0°: Illumination at 45°, measurement at 0°

Measuring area

Color difference: (L*,a*,b*), (E*ab,C*ab,H*ab), (Y,x,y), (X,Y,Z), (Rs,Gs,Bs) or (WI,YI,Tw)

Color space: (L*, a*, b*), (L*, C*ab, hab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw)

Target color memory

9 channel; set by measurement or keypad

Measuring range

L*: 5 to 100

Measurement conditions

Observe: CIE 2° Standard Observer

Illuminant

White LED lamp

Repeatability

Standard deviation within E*ab 0.5 (Measurement conditions: Average of measurements of standard white plate)

Minimum interval  between measurements

Approx. 2 seconds

Operating temperature and humidity

0~40°C(32~104°F), < 85%RH.

Storage temperature and humidity

-10~40°C(14~104°F), < 70%RH.

Power source

4x1.5 AAA (UM-4) Battery

Dimensions

140x73x35mm (5.5x2.9x1.4inches)

Weight(Not Including Batteries)

Approx. 220g with battery

Standard Accessories

Main Unit

Measuring head

White calibration card

Carrying Case (B04)

Manual

Optional Accessories

USB Data Cable with Software
