The Lovibond® Model Fx solves the temperature problems associated with consistently measuring the colour of edible oils and addresses the need for quickly delivering accurate results. Misreading from crystallisation can be eliminated with its ability to keep the oil at a constant temperature and report the temperature of the sample.
Guaranteed Temperature Consistency
The Lovibond® Model Fx solves the temperature problems associated with consistently measuring the colour of edible oils and addresses the need for quickly delivering accurate results. If samples are not properly prepared before measurement, turbidity caused by the crystallisation of the samples will lead to inconsistent readings. The integrated sample cell heater ensures consistent and uniform temperature throughout the sample resulting inaccurate measurements.
Optimised for Production Environment
Reliable and repeatable test results are key to ensuring final product quality and minimise production costs. Speed of analysis is vital for efficient process control. The simplicity of operation helps reduce errors and increase productivity. The instrument’s aluminium housing is chemical resistant and intended to withstand the hazards of the production environment.
Save Costs, Misinterpretation and Potential Disputes
Suppliers and buyers need a common language to communicate and determine product quality. The Lovibond® Model Fx automatically reports key measurements to ensure that data is collected consistently and is reproducible by different users or across multiple sites. Should disagreement occur between supplier and customer, this additional information can help resolve any dispute, saving time and costs.
Ensures Compliance to Standards
The Lovibond® Model Fx measures colour according to the Lovibond® RYBN, Lovibond® RY, Lovibond® RY10:1, AOCS Tintometer® RY, Chlorophyll & Beta-Carotene scales which are commonly used in the Edible Oil Industry. The accuracy, repeatability and reproducibility of data provided by the instrument allow for tighter colour specifications and greater colour consistency, giving companies the confidence needed to make important decisions regarding high-value commodities and refining operations.
Applicable Standard | AOCS Cc 8d-55 AOCS Cc 13b-45 AOCS Cc 13d-55 AOCS Cc 13e-92 AOCS Cc 13j-97 BS684 BS684 Section 2.20 Chinese GB/T 22460-2008 IS 548 (part 1)-2010 ISO 15305 ISO 27608 MS 252 : Part 16 MS 817 : Part 12 |
Colour Type | Transparent |
Wavelength Range | 380 - 780 nm |
Wavelength Accuracy | 0.2 nm |
Spectral Scope | < 15 nm |
Photometric Range | 0 - 100 % T |
Photometric Linearity | ± 0.01 % T |
Repeatability | ± 0.5 % T |
Stray Light | < 0.01 % T |
Detector | Spectrometer |
Interfaces | USB RS 232 |
Instrument Housing | Aluminium |
Portability | Benchtop |
Touchscreen | No |
Input Voltage | 110 VAC, 250 VAC, 60 W (24 V) |
Environmental Conditions | Temperature: +5°C - 40°C ; Humidity: Up To 90 % non condensing |
Stock Conditions | Temperature: -20°C - 85°C ; Humidity: Up To 90 % non condensing |
Compliance | CE |
Languages User Interface | English, German, French, Spanish, Italian, Portuguese, Russian, Japanese, Chinese |
Dimensions | 301 x 152 x 331 mm |
Title | Scale Path Length | Scale Range | Scale Resolution | Applicable Standard | Add to quotation cart |
---|---|---|---|---|---|
Lovibond® 10:1 | 10 mm, 1/2'', 1'', 2'' 5 1/4'' | 0.1 - 7.0 R, 1.0 - 70 Y | 0.1 unit R, 1 unit Y | Chinese GB/T 22460-2008 | |
Red and Yellow Values to Indian Standard: Castor, Ground Nut and Coconut Oil | 1" | 0 - 79.9 R, 0 - 79.9 Y, 0 - 49.9 B, 0 - 3.9 N | IS 548 (part 1)-2010 | ||
Red and Yellow Values to Indian Standard: Castor, Ground Nut and Coconut Oil | 1/4" | 0 - 70 R, 0 - 70 Y, 0 - 40 B, 0 - 3.9 N | IS 548 (part 1)-2010 | ||
Red and Yellow Values to Indian Standard: Cottonseed Oil | 1/4" | 0 - 79.9 R, 0 - 79.9 Y, 0 - 49.9 B, 0 - 3.9 N | IS 548 (part 1)-2010 | ||
AOCS-Tintometer Colour | 1/4", 1", 5 1/4" | 0 - 20 R, 0 - 70 R | 0.1 unit R, 1 unit Y | AOCS Cc 8d-55, AOCS Cc 13b-45, AOCS Cc 13j-97 | |
Lovibond® RYBN Colour | 1/16" - 6" | 0 - 70 R, 0 - 70 Y, 0 - 30 B, 0 - 3 N | 0.1 units | AOCS Cc 13e-92, AOCS Cc 13j-97, BS684, ISO 15305, ISO 27608, MS 252 : Part 16, MS 817 : Part 12 | |
Chlorophyll | 10 mm | unlimited | 1 ppm | AOCS Cc 13d-55 | |
Beta Carotene | 10 mm | 0 - 1000 ppm | 1 ppm | BS684 Section 2.20 | |
Red and Yellow Values to Indian Standard: Sesame, Mustard, Mahua Oil | 1/4" | 0 - 79.9 R, 0 - 79.9 Y, 0 - 49.9 B, 0 - 3.9 N | IS 548 (part 1)-2010 |
