Special device from Easy Test
AC/DC Gauss Meter for Magnetic measurement
AC:150.00 mT, 1500.0 mT | DC: 300.00 mT, 3000.0 mT
Unit: G (Gauss), mT (milli Tesla). (AC & DC)
Data hold, Record max/ min, Auto power off
Real time SD memory card Datalogger (1 to 16 GB)
Probe head build the Temp. Sensor (ATC)
Lutron
The MG-3003SD, Wide range, general purpose magnetic measurement, Mostly used in industrial plants such as, to measure magnetic strength that is used to suck metal debris in production lines or machines that use magnets to hold objects. The Magnetic Probe used Hall Sensor with Automatic Temperature Compensation (ATC). Convenient with Data hold, Record Max/ Min, Auto power off and LCD display with green backlight, easy reading
Datalogger Sampling Time Setting range from 1 to 3600 seconds both Auto and Manual via SD memory card (1 to 16 GB). Built-in Clock and Calendar will show with data information. The innovation and easy operation, no need to setup software, just put the SD Card into the computer. You can open file data as Excel directly.
EXCEL data screen (for example)
EXCEL graphic screen (for example)
SPECIFICATION
| Measurement | Range | Resolution | Accuracy | |
| DC | milli Tesla | 300.00 | 0.01 | ± (5% rdg + 10 digit) |
| 3,000.0 | 0.1 | |||
| Gauss | 3,000.0 | 0.1 | ||
| 30,000 | 1 | |||
| AC | milli Tesla | 150.00 | 0.01 | ± (5% rdg + 20 digit) |
| 1,500.0 | 0.1 | |||
| Gauss | 1,500.0 | 0.1 | ||
| 15,000 | 1 | |||
| Frequency Response | AC 50/60 Hz | |||
| Sensor | Hall sensor | |||
| Circuit | Custom one-chip of microprocessor LSI | |||
| Data storage | SD memory card 1 to 16 GB | |||
| Function | Auto power off, Data hold, Record max/min, Zero button for DC magnetic | |||
| Interface | RS-232, USB PC interface | |||
| Power requirement | Battery AA x 6, DC 9V adapter (optional) | |||
| Dimensions/ Weight | 181 x 68 x 45 mm/ 303 g | |||
| Manufacturer | .... |
|---|---|
| Dimensions | .. × .. cm |
| Weight | 00gm |
