DT2236B Photo/Contact Tachometer

Brand: Generic

Out of Stock

Special device from Easy Test

Specifications:

Model	DT2236B
Measuring Range	Photo Tach: 2.5 to 99999 RPM Contact Tach: 0.5 to 19999 RPM Surface Speed (m/min.): 0.05 to 1999 (m/min.)
Resolution	Photo Tach: 0.1 RPM (2.5 to 999.9 RPM), 1 RPM(over 1000 RPM) Contact Tach: 0.1 RPM (0.5 to 999.9 RPM), 1 RPM(over 1000 RPM) Surface Speed (m/min.): 0.01m/min. (0.05 to 99.99m/min.), 0.1m/min.(over 100m/min.)
Accuracy	±0.05% +1 digit
Sampling Time	0.8 sec. (over 60 RPM)
Test Range Select	Automatic
Memory	Max. value, Min. Value, Last value
Detecting Distance	50 to 500mm/2 to 20 inch (Photo)
Time Base	Quartz crystal
Circuit	Exclusive one-chip of microcomputer LSI circuit
Battery	4 x 1.5V AAA
Power Consumption	Approx 50mA (operation)
Operation Temp	0℃ to 50℃ (32℉ to 122℉)
Size	215mm x 65mm x 38mm
Weight	300g (including battery)
Accessories	Carrying case, Reflecting tape Operation manual Contact speed measurement fitting Contact rotational speed measurement fitting

Description

DIgital Photo/Contact Tachomenter DT2236 key features:

Allows user to safely measure RPM accurately without the need to attach the tachometer to the object
Provides wide measuring range and high resolution
Digital display providing exact RPM (eliminates guesswork when looking at scale)
Make use of our exclusive Micro-Computer LS-ICircuit and crystal base to offer the most accurate and fastest measurement
The last value/max, value/min will be automatically stored in memory which can be retrieved anytime
The use of durable, long lasting components, including a strong, light weight ABS-plastic housing ensures that the Tachomenter can be kept maintenance free for many years. The housing has also been specifically shaped to fit comfortably in both left and right hand.
