LTX12 Infrared Thermometer with Laser Sight and ThermoSounder

Features

• The exclusive ThermoSounder™ feature, provides users with audio feedback allowing for quick and easy detection of both cold and hot spots, without the distraction of having to follow and interpret the digital readouts
• State of the Art patented ergonomic design and styling for enhanced handling and use
• Wide temperature range: -20° to 1200° F ( -30° to 650°C)
• Optimum 10:1 distance to measurement spot ratio
• Class II laser pointer
• Large LCD display with symbols and backlight
• Quick selection between °C/°F
• Continuous reading and data hold modes
• Soft holster for instrument protection
• Auto power off

Specifications

• Display:
• 3½ digits LCD display
• Measure/Hold indicator
• Laser On indicator
• Measuring units indicator
• Backlight
• Low battery indicator
• Measurement range: -20° to 1200° F ( -30° to 650°C)
• Resolution: 0.1 to 1 (°C or °F)
• Operating Temperature: 32°F to 122°F (0°C to 50°C)
• Response time: <500 mS (approx.)
• Target Size/ Field of View: 10:1 optics ratio with a 1″ (25 mm) minimum target diameter
• Repeatability: 0.5% of reading, plus one digit
• Sensor Wavelength: 7 to 14 µm
• Emissivity: Fixed at 0.95
• Laser Pointer: Laser Diode, < 1mW output wavelength 630-670 nm, Class II
• Power Source: 9-volt battery type NEDA 1604, IEC6F22 IEC 6LR61
• Battery life: Approx. 20 hours.(w/alkaline batteries)
• Power Saving: Automatic shut off after 7 seconds
• Dimensions: 7.00″(H) x 1.88″(W) x 3.13″(D), 178 mm x 48 mm x 80 mm
• Weight: 7.6 oz or 215 g (w/ battery)

How-To

• Simply point to an object and read its temperature
• Laser sight allows for accurate targeting
• Measures objects temperatures without contact
• Safely measure temperature of hot parts and objects from a distance
• Quick response: 0.5 sec
