GM3125 Digital High Voltage Insulation Tester 5 kV

Brand: Benetech

16,500 EGP

Special device from Easy Test

Quantity:

Add to Cart

in Stock: 3
Country: China
SKU: 000
Tags:
- Electrical insulation measurement, Megger ,GM ,13125 ,GM13125 , GM-13125 , GM 13125 , insulation
Share:

Digital High Voltage Insulation Tester 5 kV

جهاز لقياس العزل الكهربى 5 كيلو فولت

Model: GM3125

صناعة الصين

High voltage insulation tester possesses the following features:

1.Auto- discharge function to make, the operation safe.
2.LCD Back-light.
3.Digital readout display.
4.Live circuit warning symbols with audio sounds.
5.Auto- power off function (in 10 minutes without operation)
6.Timer measurement function.
7.Low battery indication
8.PI measurement (Polarization index measurement)
9.Suitable for 12V DC adapter (12V/1A)

1. Insulation resistance tester:

Rated voltage	500V	1000V	2500V	5000V
Test range	0.0~99.9MΩ 100~999MΩ	0.0~99.9 MΩ 100~999 MΩ 1.00~1.99GΩ	0.0~99.9 MΩ 100~999 MΩ 1.00~1.99GΩ 10.0~99.9GΩ	0.0~99.9 MΩ 100~999 MΩ 1.00~9.99GΩ 10.0~99.9GΩ 100~1000GΩ
Open circuit voltage	DC 500V +30%, -0%	DC 1000V +20% -0%	DC 2500V +20% -0%	DC 5000V +20% -0%
Rated current	0.5MΩloading 1mA~1.2mA	1MΩ loading 1mA~1.2mA	2.5MΩ loading 1mA~1.2mA	5MΩ loading 1mA~1.2mA
Short- circuit current	Approx. 1.3mA
Accuracy	±5%rdg±3dgt (0~99.9GΩ) ±20%rdg±3dgt (above 100GΩ)

2. Voltage tester:

30~600V (Resolution 1V)

	DV	AV
Measuring range	±30~±600V	30~600V（50/60Hz）
Resolution	1V
Accuracy	±2%rdg±3dgt

3.Technology parameter:

Technology parameter	Technology index
Display	Max. 999 counts LCD display (1000 counts only at 1T is displayed)
Over range indication	OL mark appears on insulation resistance range. LO mark appears on voltage's range.
Auto- ranging	Range shifts to upper range: 1000 count Range shifts to lower range: 95 counts (merely on the insulation resistance range)
Sample rate	0.5~ 10 times/sec
Operable altitude	Less than 2000m (Indoor use)
Operation circumstance	Temperature 0~40℃, humidity <= 85%
Storage circumstance	Temperature -20~ 60 , humidity <= 90%
Overload protection	Insulation resistance : AC 1200V/ 10s Voltage : AC 720V/ 10s
Voltage resistance	AC8320 (50/60Hz)/ 5 second (between electrical circuit and enclosure)
Insulation resistance	1000M of more/ DC 1000V (between electrical circuit and enclosure)
Power supply	DC12V (8x1.5V LR14 battery)
Battery's life	Approx. 15 hours
Dimension	153x 96 ×200mm
Weight	1032g (without batteries and test wires)
