Buy TM-380 Multi IAQ Monitor

Environmental & Temperature Devices

Multi IAQ Monitor TM-380

Brand: Tenmars

17,985 EGP

This meter can make 5 measures of air quality once a time including CO2, PM2.5, PM10, temperature and humidity The measurement for CO2 is used for the air exchange rate of total heat exchangers or other ventilation fans or systems, the measurement for PM2.5 or PM10 is used for the cleaning capacit

Quantity:

Add to Cart

in Stock: 5
Country: Taiwan
SKU: 000
Tags:
- TM-380, TM 380 ,TM380 ,TM ,380 , CO2 , Dust
Share:

Features

Real-time measurement of CO2/PM2.5/PM10/temperature/humidity.

°C or °F unit selection.

Locking function for Maximum value/minimum value/average value.

Auto-shutdown function and disable auto-shutdown function.

Adjustment and calibration function (CO2/temperature/humidity).

CO2/PM2.5/PM10 red backlight alarm.

Manual record and auto-record.

Key sound assists to ensure the operation works.

CO2 /PM2.5/PM10 red backlight alarm setting function

Setting value	CO2	PM2.5	PM10
Setting value	1000PPM	35µg/m³	75µg/m³

When the measured value reaches the setting value for alarm, the LCD backlight shines in red and related measurement items flash.
Specifications

20 logs for manual and automatic recording values.
Auto-record saving interval setting: 5 seconds, 10 seconds, 5 minutes, 10 minutes, 20 minutes,
30 minutes, 60 minutes.
Sampling time: 2.5 seconds (5 types, 0.5 seconds for each).
Battery: 3.7V 2000mAh rechargeable lithium battery
Transformer for charging: 1A/5V
5V micro USB interface for external power supply
Display size: 52mm (L) x 40mm (W).
Dimension: 150 X 65 X 22mm (LxWxH)
Weight: 190g(without the batteries’ weight)

Electrical specifications

Ambient temperature range for accurate measure: 18°C (64°F) ~ 28°C (82°F)

PM2.5
Sensor	Laser particulate matter sensor
Measuring range	0-500 μg/m3
Accuracy	±8μg :<=50µg/m3 ±10% of reading value:>50µg/m3
Resolution	1
Reaction time	<10seconds

PPM10
Sensor	Laser particulate matter sensor
Measuring range	0-500 μg/m3
Accuracy	±10μg :<=50µg/m3 ±15% of reading value:>50µg/m3
Resolution	1
Reaction time	<10 seconds

CO2
Sensor	Non-Dispersion Infrared(NDIR)
Measuring range	400 to 9999ppm
Accuracy	±70ppm ±3% of readings. (400-2000ppm)
Resolution	±1ppm
Reaction time	90% during about 2 minutes

Temperature
Sensor	Bandgap temperature sensor
Effective range	-10°C~50°C / 14°F~122°F
Accuracy	±1.0°C/±1.8°F (Non-charging and 30 minutes after charging)
Resolution	0.1°C / 0.1F (0~35°C / 32°F~95°F) ; 1°C / 1°F (Above 100°C /°F or below -10°C /°F)
Reaction time	About 1 second

Humidity @25°C
Sensor	Capacitive humidity sensor
Effective range	1-99%
Accuracy	±5.0%RH(10~90%); ±8.0%RH(<10%,>90%) no condensation, at 25°C
Resolution	0.1%
Reaction time	About 4 seconds
