This unit consists of optics, a temperature sensor signal amplifier, processing circuitry, and an LCD display The optics collect the infrared energy emitted by the object and focus it on the sensor. The sensor then translates the energy into an electrical signal. This signal will be digital and
Features :
| Temperature range | GM531: -50~530℃ (-58~986℉) |
| Accuracy | 0~400℃/530 (32~752℉/986 ) : ±1.5℃(±2.7℉) or ±1.5% -50~0℃(-58~32℉):±3℃ (±5℉) Whichever is greater |
| Repeatability | 1% of reading or 1℃ |
| Response time | 500 mSec, 95% response |
| Spectral response | 5~14 um |
| Emissivity | 0.10~1.00optional (0.95 Preset) |
| Distance to Spot size | 12:1 |
| Operating Temperature | 0 ~40℃ (32 ~ 104℉) |
| Operating Humidity | 10~95%RH non-condensing， up to 30℃(86℉) |
| Storage Temperature | -20 ~ 60℃ (-4~140℉) |
| Power | 3V (1.5V AAA * 2) |
| Typical battery life (Alkaline) | Laser Models:12 hrs |
| Manufacturer | Elmetron |
|---|---|
| Dimensions | .. × .. cm |
| Weight | 00gm |
