GT230 Film Coating Thickness Gauge

Brand: Benetech
8,250 EGP

Special device from Easy Test

Quantity:
+

This Coating Thickness Gauge thermometer possesses the following features:

1. Menu operation and color-screen HD display.

2. Thickness measurement of non-magnetic coating on magnetic metal substrate surface and non-metallic coating on non-magnetic metal substrate.

3. Two measurement methods: single measurement, continuous measurement.

4. Basic calibration and Zero-point calibration available.

5. Metric/imperial unit and storage function.

6. Screen rotation, charge protection, multi-interface displays, screen brightness selection.

7. Automatic shutdown.

Measurement range0 ~ 1300um/51mil
Resolution( 0.1μm(<100μm),1μm( ≥100μm))/0.1mil
Measurement error≤150μm  ±5μm
>150μm ±(3%H+1μm)
Minimum diameter of magnetic metal substrate12mm
Minimum thickness of magnetic metal substrate0.5mm
Minimum radius of curvature for magnetic convex substrate2mm
Minimum radius of curvature for magnetic concave substrate11mm
Minimum diameter of non-magnetic metal substrate50mm
Minimum diameter of non-magnetic metal substrate50mm
Minimum thickness of non-magnetic metal substrate0.5mm
Working voltageDC 3.7V (Lithium battery capacity 1000mAh)
Size52.9*26*117mm
Weight102.4g(including battery)

Product Specifications

Manufacturer....
Dimensions.. × .. cm
Weight00gm
