A professional handheld 2-in-1 digital instrument engineered to precisely measure moisture content in wood, timber, and building materials alongside ambient temperature. Features integrated high-penetration steel test pins, a multi-metric backlit LCD screen
Standardize Quality Inspection and Prevent Structural Fiber Defects with the MC-7806
Ensure optimal material readiness, prevent structural warping, and eliminate hidden humidity anomalies with the professional diagnostics of the MC-7806 Digital 2-in-1 Moisture Meter. Tailored specifically for woodworkers, lumber mills, construction inspectors, and furniture manufacturers, this handheld metrology tool delivers dual tracking capabilities. By utilizing high-precision conductivity steel pins to measure electrical resistance across raw materials, the MC-7806 provides instantaneous relative water-content tracking alongside dedicated ambient temperature readings.
Dual-Function Moisture & Temperature Metrics: Combines material relative moisture analysis ($0\text{ to }50\%$) and ambient thermal testing ($ -10\text{ to }65^\circ\text{C}$) into a single portable instrument, streamlining quality control workflows.
Streamlined 5-Button Control Panel: Outfitted with an intuitive color-coded central navigation pad featuring SET, ZERO, PEAK, UNIT, and a prominent central Power button. This setup allows operators to freeze maximum peak values, execute air calibration, or toggle temperature metrics easily.
High-Contrast Digital LCD Viewport: Outfitted with an integrated digital LCD screen that maps live measurements, low battery notifications, and status codes clearly, preventing tracking errors on dark or active jobsites.
Automatic Temperature Compensation (ATC): Features internal microprocessing logic that actively recalculates moisture percentages relative to surrounding thermal shifts, guaranteeing reliable data regardless of winter cold or summer heat storage conditions.
| Feature | Specification |
|---|---|
| Model Identification | MC-7806 Digital 2-in-1 Series |
| Measurement Principle | Electrical Resistance Conductivity Method (Pin-Type) |
| Moisture Measuring Range | 0% to 50% Moisture Content (MC) |
| Control Pad Interface Configuration | 5-Button Matrix Layout (SET, ZERO, PEAK, UNIT, Red Power Switch) |
| Display Panel Layout | Integrated multi-metric digital LCD viewport |
| Sensor Interface Hardware | Fixed top-mounted heavy-duty dual steel penetration pins |
| Power Source | $4 \times 1.5\text{V AA}$ (UM-4) Batteries |
