A YK-2001PHA portable device for measuring water quality and its properties.

• One meter for multi purpose operation : pH/ORP, CD/TDS, Dissolved Oxygen, Salt measurement.
• pH : 0 to 14.00 pH, ORP : ± 1999 mV.
• Conductivity : 200 uS/2 mS/20 mS/200 mS.
• Dissolved oxygen : 0 to 20.0 mg/L.
• Salt : 0 to 12 % salt ( % weight )
• Optional pH, ORP, CD/TDS/Salt, Dissolved Oxygen and ATC probe
• DC 9V ( 006 P ) or DC 9V adapter in.

Description

Lutron YK-2001PHA pH/ORP, DO, CD/TDS, Salt Meter

Features Lutron YK-2001PHA pH/ORP, DO, CD/TDS, Salt Meter

• One meter for multi purpose operation : pH/ORP, CD/TDS, Dissolved Oxygen, Salt measurement.
• pH : 0 to 14.00 pH, ORP : ± 1999 mV.
• Conductivity : 200 uS/2 mS/20 mS/200 mS.
• Dissolved oxygen : 0 to 20.0 mg/L.
• Salt : 0 to 12 % salt ( % weight )
• Optional pH, ORP, CD/TDS/Salt, Dissolved Oxygen and ATC probe
• DC 9V ( 006 P ) or DC 9V adapter in.
• pH meter function can select pH or ORP.
• pH measurement can select ATC or manual temperature adjustment.
• pH measurement can make the auto calibration for pH 7, pH 4 and pH 10 or other value.
• Conductivity measurement can select uS/mS or TDS
• Conductivity measurement can select Temp. Coefficient of measurement solution
• ATC for the conductivity measurement.
• Dissolved oxygen meter use the polar graphic type oxygen probe with temperature sensor, high precision measurement for Dissolved Oxygen ( DO ) and temperature measurement
• Heavy duty dissolved oxygen probe, probe head can connect with BOD bottle.
• DO use the automatic Temp. compensation.
• DO meter build in ” % SALT ” & ” Mountain Height ” compensation value adjustment.
• Separate probe, easy for operation of different measurement environment.
• Wide applications: water conditioning, aquariums, beverage, fish hatcheries, food processing, pHotograpHy, laboratory, paper industry, plating industry, quality control, school & college, water conditioning.
• LCD with green light backlight, easy reading.
• Can default auto power off or manual power off
• Data hold, record max. and min. reading.
• Microcomputer circuit, high accuracy
• Power by DC 9V battery ( 006 P ) or DC 9V adapter
• RS232/USB PC COMPUTER interface.

Specifications Lutron YK-2001PHA pH/ORP, DO, CD/TDS, Salt Meter

• Circuit: Custom one-chip of microprocessor LSI circuit.
• Display:
  * LCD size : 52 mm x 38 mm
  * LCD with green backlight ( ON/OFF ).
• Measurement Function:
  * pH/ORP
  * Conductivity/TDS(Total Dissolved Solids)
  * Dissolved Oxygen
  * Salt
• Advanced setting:
  * Auto power OFF management
  * Set beep Sound ON/OFF
  * Set temperature unit to ℃ or ℉
  * Set DO salt% compensation value
  * Set DO height ( meter ) compensation value
  * Set CD temperature compensation factor
  * Set CD to TDS or TDS to CD, CD only
  * Set pH manual Temp. compensation value
• Data Hold: Freeze the display reading.
• Memory Recall: Maximum & Minimum value
• Sampling Time of Display: Approx. 1 second.
• Data Output: RS 232/USB PC computer interface
• Operating Temperature: 0 to 50℃ .
• Operating Humidity: Less than 85% R.H.
• Power Supply:
  * Alkaline or heavy duty DC 9V ( 006 P ) battery or equivalent.
  * DC 9V adapter input. ( AC/DC power adapter is optional ).
• Power Current:
• Normal operation ( LCD Backlight is OFF) : Approx. DC 14 mA.
• Weight: 489 g/1.08 LB.
• Dimension: 177 x 68 x 45 mm (7.0 x 2.7x 1.9 inch)

Accessories Included:

• Instruction manual……………………………..1 PC
• Conductivity/TDS/Salt probe, CDPB-03……1 PC

Optional Accessories:

• Hard carrying case, CA-06.
• pH electrode…………………..PE-03, PE-11, PE-01, PE06HD PE-04HD, PE-03K7
• ATC probe ( Automatic Temperature Probe )…………………………………..TP-07
• pH 7 buffer solution…………………. pH-07
• pH 4 buffer solution…………………..pH-04
• Pt type Conductivity/TDS probe, Salt probe……………………………….CDPB-04
• 1.413 mS Conductivity Standard Solution………………………………….CD-14
• Oxygen probe………………………….OXPB-11
• Spare Probe head with DiapHragm set…………………………………………….OXHD-04
• Probe-filling Electrolyte………………OXEL-03
• ORP Electrode………………………….ORP-14
• AC to DC 9V adapter.
• USB cable, USB-01.
• RS232 cable, UPCB-02.
• Data Acquisition software,SW-U801-WIN.
• Excel Data Acquisition software,SW-E802
