Designed specifically for automotive maintenance and repair technicians Temperature range of -13°F to 1022°F 160 × 120 thermal resolution (19,200 pixels) Helps to accelerate diagnostic procedures and avoid undetected problems Combines non-contact temperature measurement and thermal imaging
| Image and Optical Data | |
| IR Resolution | 160 × 120 (19,200 pixels) |
| Thermal Sensitivity/NETD | <70 mK |
| Field of View | (FOV) 57° × 44° |
| Distance-to-Spot Ratio | 30:1 |
| Minimum focus distance | 0.3 m (0.98 ft.) |
| Imaging Range | –25°C to 550°C (–13°F to 1022°F) |
| Image Frequency | 8.7 Hz |
| Focus | Fixed |
| Digital Camera | 2 MP, 71° × 56° FOV |
| Image Presentation and Modes | |
| Display Resolution | 320 × 240 pixels |
| Screen Size | 2.4" color LCD, portrait orientation |
| Aspect Ratio | 4:3 |
| Image Adjustment | Automatic |
| Visual Image | Yes |
| MSX® | Yes |
| Gallery | Yes |
| Color Palettes | Iron, Rainbow, White hot, Black hot, Arctic, Lava |
| Image Storage Capacity | 4 GB for storage of up to 50,000 pictures |
| Image File format | JPEG |
| Measurement and Analysis | |
| Camera Temperature Range | –25°C to 550°C (–13°F to 1022°F) |
| Measurement Accuracy | ±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F) Up to ±3°C (±5.4°F) for temperatures -25°C to 50°C (-13°F to 122°F) Up to ±3°C (±5.4°F) for temperatures 100°C to 550°C (212°F to 1022°F) |
| IR Temperature Resolution | 0.1°C (0.2°F) |
| IR Thermometer Measurement | Continuous scanning |
| Spot Meter | Center spot on/off |
| Emissivity correction | Yes: 4 preset levels with custom adjustment of 0.1 to 0.99 |
| Set-up Commands | Local adaptation of units, language, date, 0.99 Screen Brightness (high, medium, low) Gallery, deletion of images |
| General | |
| Laser pointer | Center spot and circular area |
| Laser | Class 1 |
| Interfaces | USB 2.0, Bluetooth® BLE |
| USB | USB Type-C: data transfer/power |
| Available Languages | Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, simplified Chinese, Spanish, Swedish, traditional Chinese, Turkish |
| Flashlight | Bright LED flashlight |
| Battery Operating Time | 5 hours continuous scanning |
| Battery Type | Rechargeable Li-ion battery |
| Battery Voltage | 3.7 V |
| Battery Charging Time | 4 hours to 90%, 6 hours to 100% |
| Power Management | Adjustable: off, 5 min, 15 min, 30 min |
| IP Rating | IP54 (IEC60529) |
| Drop | Designed for 2 m (6.56 ft.) |
| Safety | CE/CB/EN61010/UL |
| Operating Temperature Range | –10°C to 45°C (14°F to 113°F) |
| Tripod mounting | UNC 1/4”-20 |
| Weight (including battery) | 0.394 kg (13.9 oz.) |
| Size (L x W x H) | 210 mm × 64 mm × 81 mm (8.3" × 2.5" × 3.2") |
| Box Contents | Thermal camera, wrist strap lanyard, USB cable, pouch, printed documentation |
Thermal Imagers/Building and Industrial Thermal Imagers Template | |
|---|---|
Test Equipment General Attributes | |
| Detector Size | 160 x 120 Sensor |
| Thermal Sensitivity | 70 mK (NETD) |
| Temperature Range Max | 1022 F |
| Temperature Range Min | -13 F |
| Image Frequency | 8.7 Hz |
| Field of View | 57 x 44 Degrees |
| Screen Size | 2.4 IN |
| IR/Overlay Fusion Image | Yes |
| Video Output | No |
| Focus | Fixed |
| Laser Spot | Yes |
| Picture in Picture | Yes |
| Video Recording | No |
| Moveable Spots | No |
| Touch Screen Display | No |
| Minimum Focus Distance | 0.3 M |
| Accuracy | ±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F) Up to ±3°C (±5.4°F) for temperatures -25°C to 50°C (-13°F to 122°F) Up to ±3°C (±5.4°F) for temperatures 100°C to 550°C (212°F to 1022°F) |
| Battery operating time Continuous | 5 HR |
| Camera Light | Yes |
| IR Digital Zoom | No |
| Voice Annotation | No |
| Intrinsically Safe | No |
| Product Weight | 13.9 OUNCES (0.869 LBS) |
| Product Height | 3.2 IN |
| Product Length | 8.3 IN |
| Product Width | 2.5 IN |
| Shipping Weight | 5 LBS |
| HTS/Schedule B Number | 9027.50.4020 |
| ECCN Number | 6A993 |
| Country of Origin | Taiwan |
| Shipping Height | 4.12 IN |
| Shipping Length | 11.2 IN |
| Shipping Width | 5.95 IN |
| Other Information | True thermal imager: 19,200 pixels |
| Manufacturer | flir |
|---|---|
| Dimensions | .. × .. cm |
| Weight | 00gm |
